Toro GrandStand 74534TE - Cushion Release for Rear Access

Figure35
1.Removebattery
2.Withtwopeople,liftthe
frontendofthemower
(ensuretheplatformisup)
ReleasetheCushionforRear
Access
Thecushioncanbereleasedforrearaccesstothe
machineformaintenanceoradjustment.
1.Lowertheplatform.
2.Removethehairpincotterpinsoneachsideofthe
cushion.
3.Slidethelargewasherswithplasticbushingstothe
inside.
4.Removethecushionandlowerittotheplatform.
5.Performanymaintenanceoradjustmentonthe
machine.
6.Raisethecushionandslideitontothepinsonboth
sidesofthemachine(
Figure36).
7.Slidethelargewasherswithplasticbushingsinto
thecushionbracketandsecurethemwithahairpin
cotterpin(Figure36).
g012572
1
2
3
4
Figure36
31
