Toro GrandStand 74568TE - Positioning the Flow Baffle; Using the MID-Size Weight

PositioningtheFlowBafe
Thefollowingguresareonlyrecommendationsfor
use.Adjustmentswillvarybygrasstype,moisture
content,andheightofgrass.
Note:Iftheenginepowerdrawsdownandthemower
groundspeedisthesame,openupthebafe.
PositionA
Thisisthefullrearposition(seeFigure29).The
suggesteduseforthispositionisafollows.
•Useforshort,lightgrassmowingconditions.
•Useindryconditions.
•Forsmallergrassclippings.
•Propelsgrassclippingsfartherawayfromthe
mower.
G012677
Figure29
PositionB
Usethispositionwhenbagging(Figure30).
G012678
Figure30
PositionC
Thisisthefullopenposition.Thesuggestedusefor
thispositionisasfollows(Figure31).
•Useintall,densegrassmowingconditions.
•Useinwetconditions.
•Lowerstheenginepowerconsumption.
•Allowsincreasedgroundspeedinheavyconditions.
G012679
Figure31
UsingtheMid-SizeWeight
•Weightsareinstalledtoimprovehandling,balance
andimproveperformance.Weightscanbeaddedor
removedtocreateoptimizedperformanceunder
differentmowingconditionsandforoperator
preference.
•Itisrecommendedthatweightsbeaddedor
removedoneatatimeuntilthedesiredhandingand
balanceisachieved.
26
