Toro GrandStand Mulching Kit - Removing the Baffles

angelocknuts(3/8inch)thatsecurethekicker
ttingtothedeck,andremovethekickertting
(Figure9).
Note:Retainthecarriageboltsandkickertting
forinstallingthemulchingkit.
g283725
Figure9
1.Flangelocknut(3/8inch)4.Carriagebolt(3/8x1inch)
2.10mm(3/8inch)hole
(mowerdeck)
5.Frontofthemachine
3.Kickertting
4.Install2ange-headcapscrews(3/8x1inch)
intothe10mm(3/8inch)holesinthemower
deck(Figure10)andsecurethecapscrewswith
2angelocknuts(3/8inch)thatyouremoved
instep3.
g284328
Figure10
1.Flangelocknut(3/8inch)
3.Flange-headcapscrew
(3/8x1inch)
2.10mm(3/8inch)hole
(mowerdeck)
RemovingtheBafes
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
1.Removethe3carriagebolts(3/8x1inch)and
3angelocknuts(3/8)thatsecuretheleftbafe
tothesideofthedeckandtherightbafe,and
removetheleftbafe(Figure11).
Note:Retainthecarriagebolts,angelocknut,
andbafeforinstallingthemulchingkit.
g283717
Figure11
1.Flangelocknut(3/8inch)4.Rightbafe(4holes)
2.10mm(3/8inch)hole
(mowerdeck—side)
5.Frontofthemachine
3.Leftbafe(3holes)
2.Install2ange-headcapscrews(3/8x1inch)
intothe10mm(3/8inch)holesinthemower
deck(Figure12)andsecurethecapscrewswith
2angelocknuts(3/8inch)thatyouremoved
instep1.
g284333
Figure12
1.Flangelocknut(3/8inch)
3.Flange-headcapscrew
(3/8x1inch)
2.10mm(3/8inch)hole
(mowerdeck—side)
3.Removethe3carriagebolts(3/8x1inch)and3
angelocknuts(3/8)thatsecuretherightbafe
7
