InstallingtheGrassBasket
Partsneededforthisprocedure:
1
Grassbasket
Procedure
Graspbasketbytoplipandslideitontothebasket
mountingrods(Figure8).
Figure8
1.Grassbasket
2.Basketmountingrod
Note:Model04060only—Whencuttinginhigher
heights-of-cut,thebasketmaybeloweredbyremoving
eachbasketmountingrodandinstallingeachonthe
oppositesideofthemachine.
ProductOverview
Controls
Figure9
1.Tractiondrivelever
3.On/offswitch
2.Throttlecontrol
4.Service/parkingbrake
ThrottleControl
Thethrottlecontrol(Figure9)islocatedonrearright
sideofthecontrolpanel.Theleverconnectstoand
operatesthrottlelinkagetothecarburetor.Theengine
speedcanbevariedfrom1600to3600RPM.
TractionDriveLever
Thetractiondrivelever(Figure9)islocatedonthefront
rightsideofthecontrolpanel.Ithastwopositions:
NeutralandForward.Pushingtheleverforwardengages
thetractiondrive.
Service/ParkingBrake
Theservice/parkingbrake(Figure9)islocatedonleft
frontsideofcontrolpanel.Youcanusethebraketo
sloworstopthemachine.Pullingtheleverbackover
centerwillsettheparkingbrake.Youmustreleasethe
brakebeforetractiondriveisengaged.
On/OffSwitch
Theon/offswitch(Figure9)islocatedonthetopofthe
controlpanel.MoveswitchtotheOnpositiontostart
theengineandtheOffpositiontostoptheengine.
OperatorPresenceControl(Optional)
Ifequipped,theoperatorpresencecontrol(Figure9)
islocatedontherearofthehandle.Pushtheoperator
presencecontrolagainstthehandle.Ifequipped,the
operatorpresencecontrolmustbeengagedbefore
movingthetractiondriveleverortheenginewillstop.
