InstallingtheSeat
Partsneededforthisprocedure:
1
Seat-completionkit
Procedure
Acquireyourdesiredseatkitfromyourdistributorand
installittothemachine;refertothekitInstallation
Instructions.
3
InstallingtheSteering
Wheel
Partsneededforthisprocedure:
1
Steeringwheel
1
Locknut(1-1/2inches)
1Washer
1
Steering-wheelcap
Procedure
1.Slidethesteeringwheelontothesteeringshaft
(Figure4).
g010834
Figure4
1.Steeringwheel
3.Locknut
2.Washer
4.Cap
2.Slidethewasherontothesteeringshaft(Figure
4).
3.Securethesteeringwheeltotheshaftwitha
locknutandtightenitto27to35N∙m(20to26
ft-lb)(Figure4).
4.Installthecaptothesteeringwheelandsecure
itwith6bolts(Figure4).
