InfoCenterIconDescriptions(cont'd.)
Right
Left
Bulb
OutputofTECcontrollerorcontrol
wireinharness
Switch
Operatormustreleaseswitch
Operatorshouldchangetoindicated
state
Symbolsareoftencombinedtoformsentences.Some
examplesareshownbelow.
Operatorshouldputmachinein
neutral
Enginestartisdenied
Engineshutdown
Enginecoolantistoohot
DPFashaccumulationnotication.
RefertoServicingtheDiesel
ParticulateFilter(DPF)inthe
maintenancesectionfordetails
Reset-standbyregenerationrequest
Parkedorrecoveryregeneration
request
Aparkedorrecoveryregenerationis
processing.
Highexhausttemperature
NOxcontroldiagnosismalfunction;
drivethemachinebacktotheshop
andcontactyourauthorizedT oro
distributor(softwareversionUand
later).
Thepowertake-offisdisabled.
InfoCenterIconDescriptions(cont'd.)
Sitdownorengagetheparking
brake.
Indicatesthatlimitedliftreverseis
active.
AccessibleonlybyenteringPIN
UsingtheMenus
ToaccesstheInfoCentermenusystem,pressthe
menuaccessbuttonwhileatthemainscreen.This
displaysthemainmenu.Refertothefollowingtables
forasynopsisoftheoptionsavailablefromthemenus:
MainMenu
MenuItemDescription
Faults
Containsalistoftherecent
machinefaults.Referto
theServiceManualoryour
authorizedTorodistributorfor
moreinformationontheFaults
menuandtheinformation
containedthere.
DiagnosticsListsvariousstatesthatthe
machinecurrentlyhas;you
canusethistotroubleshoot
certainissuesasitquicklytells
youwhichmachinecontrols
areonandwhichareoff.
ServiceContainsinformationonthe
machinesuchashoursofuse,
counters,andothersimilar
numbers.
Settings
Allowsyoutocustomizeand
modifycongurationvariables
ontheInfoCenterdisplay.
AboutListsthemodelnumber,serial
number,andsoftwareversion
ofyourmachine.
Service
MenuItemDescription
Hours
Liststhetotalnumberofhours
thatthemachine,engine,and
PTOhavebeenon,aswell
asthenumberofhoursthe
machinehasbeentransported
andservicedue
Counts
Listsnumerouscountsthe
machineexperienced
DPFRegeneration
Thedieselparticulatelter
regenerationoptionandDPF
submenus
15
