Features
• Station based flow management reduces nighttime water
window and optimizes pump capacity.
• Variable Length (VL) communication reduces download
time by up to 80%.
• Current sensing monitors each station output for proper
amperage draw with user defined thresholds.
• Intuitive user interface with backlit display for better low-
light viewing.
• Optional output switches and surge protection
• Multi-Manual, Program Start and Syringe manual
operations
• Group Multi-Manual operation
• Sturdy plastic or painted stainless steel pedestals
• Operates as a stand-alone controller, or under the
management of a central computer
• Supports wireline or radio communications
• Supports hybrid communication (wireline and radio) for
increased flexibility and cost effectiveness.
• 64 irrigation programs: independent stand-alone and
central operation
• Basic, Advanced and Grow-in programs
• Pause, Resume and Stop functions
• Supports run times from 1 second to 23:59:59
• Percent adjust from 1% to 900% (Station, Program,
Satellite)
Features (continued)
• Each output can be defined as an irrigation station or
general application switch
• Non-volatile memory retains program information and
satellite settings during power-off conditions. Battery back-
up retains the satellite date and time
• 16-64 stations in 8-station increments – 64 programs
• Individual station control and the ability to run up to 32
stations simultaneously
• Backwards compatible with Network 8000 satellites.
Electrical Specifications
Input Power:
• 108 V ac to 132 V ac, 60 Hz
• 0,20 amps (no load) 115 V ac
• 1,20 amps (max load) 115 V ac
• 216 V ac to 264 V ac, 50 Hz
• 0,10 amps (no load) 230 V ac
• 0,60 amps (max load) 230 V ac
Output Power:
• 24 V ac
• 3,0 amps (max total load)
• UL Listed
Additional Specifications
• Operating temperature: -10°C to 60°C (15°F to 140°F)
• Storage temperature: -30°C to 65°C (-22°F to 149°F)
• Humidity: 0% to 95% RH (non-condensing)
Dimensions
• Plastic Cabinet: 41cm W x 99cm H x 41cm D
(17” W x 40” H x 16” D)
• Metal Cabinet: 33cm W x 91cm H x 33cm D
(13” W x 36” H x 13” D)
Warranty
• 1 Year
Specifying Information—Network VP Satellites
201-XXX6XX
Description Configuration Cabinet Output Comm.
Options
201 XX X 6 X
X
201—Network
VP Satellite
16—16 Stations 24—24 Stations
32—32 Stations 40—40 Stations
48—48 Stations 56—56 Stations
64—64 Stations
P—Plastic, Green
S—Stainless Steel (Painted)
T—Desert Sand
B—Tree Bark
6—24 VAC Electric A—Stand-alone
M—2-Way Wire Modem
R—UHF Radio
0—No Options
1—Large-capacity Terminal Block w/Standard Surge
2—Large-capacity Terminal Block w/Add’l Surge
3—Large-capacity Terminal Block & Switches
4—Large-capacity Terminal Block w/Add’l Surge & Switches
Example: When ordering a 24-station, Stand-alone VP Satellite in a plastic cabinet with large-capacity terminal block, additional surge and switches,
you would specify: 201-24P6A4
Radio option not available in all locations, please check with your Toro representative for availability.
Network VP
®
Satellites
Pedestal available in standard
Green, Desert Sand and Tree Bark
Upgrade kits include a new timing
mechanism and power distribution
board and a full installation can
be completed in minutes per
controller. Network LTC Plus
Upgrade Kit consists of Network VP
faceplate, power distribution board,
and interface cable.
Upgrade Kit -
Network LTC® Plus to Network VP
Specifying Information—Network LTC Plus Upgrade Kit
118-0038
Kit Contains
Network VP Faceplate, Network LTC Plus To Network VP Power Distribution Board, Cable And Hardware
