Toro Lynx User Manual

24
DT54 Series Performance Chart—25° (Metric)
Front
Nozzle
Positions
Nozzle Set 51
(Yellow)
Nozzle Set 52
(Blue)
Nozzle Set 53
(Brown)
Nozzle Set 54
(Orange)
Nozzle Set 55
(Green)
Nozzle Set 56
(Gray)
Nozzle Set 57
(Black)
Nozzle Set 58
(Red)
Nozzle Set 59
(Beige)
102-0725 102-7001 102-0727 102-7002 102-6908 102-0730 102-4261 102-4260 102-4259
Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Brown Red Plug Brown Red Plug Red Plug
102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-6883 102-4335 102-6883 102-4335 102-4335
Back Nozzle
Positions
Yellow Blue Yellow Orange Yellow Red Yellow Beige Yellow Beige Yellow Red Yellow Gray Yellow Gray Yellow Gray
102-6937 102-2925 102-6937 102-2926 102-6937 102-2928 102-6937 102-2929 102-6937 102-2929 102-6937 102-6944 102-6937 102-6945 102-6937 102-6945 102-6937 102-6945
Bar kPa kg/cm2 Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM
3,4 340 3,47 17,7 50,0 18,0 59,4 19,5 83,3 21,4 99,2 - - - - - - - - - -
4,5 450
4,59 18,3 56,0 18,6 66,2 20,7 93,9 22,6 110,9 24,1 129,4 - - - - - - - -
5,5 550 5,61 18,6 62,1 19,5 75,7 22,0 104,5 23,8 123,4 25,3 143,8 25,9 154,0 26,5 169,9 27,8 190,0 29,3 210,4
6,9 690 7,04 19,2 68,5 20,4 89,3 22,9 115,1 24,7 138,9 26,5 160,9 27,5 173,4 28,4 190,0 29,0 209,7 30,2 233,9
DT54 Series Performance Chart—15°
Bar kPa kg/cm2 Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM
3,4 340 3,47 15,9 50,0 16,2 59,8 18,6 83,3 19,8 98,4 - - - - - - - - - -
4,5 450 4,59 16,2 56,0 16,5 65,9 19,2 93,9 20,4 110,5 21,0 129,1 - - - - - - - -
5,5 550 5,61 17,1 62,1 17,7 73,4 20,7 104,5 22,0 123,0 22,9 143,1 24,1 152,9 24,7 168,8 25,9 188,9 26,5 209,3
6,9 690 7,04 17,7 68,5 18,3 79,9 21,7 115,1 22,9 137,8 24,1 160,1 25,6 172,2 26,5 188,9 27,1 208,6 28,7 232,8
Stator 102-6929 Blue 102-1940 White 102-1941 White
Conversions DT54-5154 DT54-5558 DT54-59
DT54 Nozzle Apex - (U.S.)
Pressure Nozzle Apex at 15˚ Apex at 25°
65 PSI
51 6’ @ 51’ 13’ @ 54’
52 6’ @ 51’ 11’ @ 64’
53 7’ @ 59’ 13’ @ 68’
54 8’ @ 63’ 15’ @ 74’
55 9’ @ 66’ 15’ @ 76’
80 PSI
56 8’ @ 75’ 18’ @ 83’
57 9’ @ 74’ 19’ @ 82’
58 10’ @ 82’ 18’ @ 87’
59 11’ @ 81’ 21’ @ 91’
DT54 Nozzle Apex - (Metric)
Pressure Nozzle Apex at 15˚ Apex at 25°
4,5 Bar
51 1,8 @ 15,6 4,0 @ 16,5
52 1,8 @ 15,6 3,4 @ 19,5
53 2,1 @ 18,0 4,0 @ 20,7
54 2,4 @ 19,2 4,6 @ 22,6
55 2,7 @ 20,1 4,6 @ 23,2
5,5 Bar
56 2,4 @ 22,9 5,5 @ 25,3
57 2,7 @ 22,6 5,8 @ 25,0
58 3,0 @ 25,0 5,5 @ 26,5
59 3,4 @ 24,7 6,4 @ 27,1
DT54 Series
Full Circle Sprinklers
DT54 Series Performance Chart— 25° (U.S.)
Front
Nozzle
Positions
Nozzle Set 51
(Yellow)
Nozzle Set 52
(Blue)
Nozzle Set 53
(Brown)
Nozzle Set 54
(Orange)
Nozzle Set 55
(Green)
Nozzle Set 56
(Gray)
Nozzle Set 57
(Black)
Nozzle Set 58
(Red)
Nozzle Set 59
(Beige)
102-0725 102-7001 102-0727 102-7002 102-6908 102-0730 102-4261 102-4260 102-4259
Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Brown Red Plug Brown Red Plug Red Plug
102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-6883 102-4335 102-6883 102-4335 102-4335
Back Nozzle
Positions
Yellow Blue Yellow Orange Yellow Red Yellow Beige Yellow Beige Yellow Red Yellow Gray Yellow Gray Yellow Gray
102-6937 102-2925 102-6937 102-2926 102-6937 102-2928 102-6937 102-2929 102-6937 102-2929 102-6937 102-6944 102-6937 102-6945 102-6937 102-6945 102-6937 102-6945
PSI Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM
50 58 13.2 59 15.7 64 22.0 70 26.2 — — — — — — — — — —
65 60 14.8 61 17.5 68 24.8 74 29.3 79 34.2 — — — — — — — —
80 61 16.4 64 20.0 72 27.6 78 32.6 83 38.0 85 40.7 87 44.9 91 50.2 96 55.6
100 63 18.1 67 23.6 75 30.4 81 36.7 87 42.5 90 45.8 93 50.2 95 55.4 99 61.8
DT54 Series Performance Chart—15°
psi Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM
50 52 13.2 53 15.8 61 22.0 65 26.0 — — — — — — — — — —
65 53 14.8 54 17.4 63 24.8 67 29.2 69 34.1 — — — — — — — —
80 56 16.4 58 19.4 68 27.6 72 32.5 75 37.8 79 40.4 81 44.6 85 49.9 87 55.3
100 58 18.1 60 21.1 71 30.4 75 36.4 79 42.3 84 45.5 87 49.9 89 55.1 94 61.5
Stator 102-6929 Blue 102-1940 White 102-1941 White
Conversions DT54-5154 DT54-5558 DT54-59
■ Not recommended at these pressures. Radius shown in feet.
Toro recommends the use of a 1
1
⁄4" swing joint at flows over 25-GPM (95-LPM). Sprinkler radius of throw per ASAE standard S398.1.
All sprinklers are equipped with the selectable pilot valve that allows settings at 50, 65, 80 and 100 psi.
