Toro Power Clear 621 QZR - Initial Setup Procedures; Loose Parts Verification; Handle Unfolding and Adjustment; Cable Protection During Setup

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
1
Nopartsrequired
–
Unfoldthehandle.
Screws
3
2
Chuteassembly
1
Installthedischargechute.
1
UnfoldingtheHandle
NoPartsRequired
Procedure
1.Loosenthehandleknobs,pulloutthe“U”-shaped
handlelocksuntilyoucanmovethehandlefreely,and
rotatethehandletotheoperatingposition(Figure4).
Figure4
1.“U”-shapedhandlelock(2)
2.Handleknobs
2.Inserttheendofthe“U”-shapedhandlelockintothe
openholeinthehandleandtightenthehandleknobs
untiltheyaresnug(Figure5).
Figure5
Important:Ensurethatyoudonotpinchorkink
thecontrolcableortheQuickShoot™cables
(Figure6).
Figure6
1.Controlcable2.QuickShoot™cables
5
