4
AdjustingtheControlCable
NoPartsRequired
Procedure
RefertoAdjustingtheControlCableinMaintenance.
ProductOverview
Figure10
1.Chutedeectortrigger
8.Electric-startbutton
(model38459only)
2.Dischargechute9.Ignitionkey
3.Fueltankcap
10.Chokelever
4.Controlbar11.Oildrainplug
5.QuickShoot™control12.Oilllcap
6.Recoilstarthandle
13.Chutedeector
7.Primer
7
