Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
1
Nopartsrequired
–
Unfoldthehandle.
Screws
3
Chuteassembly
1
2
Dischargechutehandle1
Installthedischargechute.
1
UnfoldingtheHandle
NoPartsRequired
Procedure
1.Loosenthehandleknobs,pulloutthe“U”-shaped
handlelocksuntilyoucanmovethehandlefreely,
androtatethehandletotheoperatingposition
(
Figure4).
Figure4
1.“U”-shapedhandlelock(2)
2.Handleknobs
2.Inserttheendofthe“U”-shapedhandlelockinto
theopenholeinthehandleandtightenthehandle
knobsuntiltheyaresnug(Figure5).
Figure5
Important:Ensurethatyoudonotpinchor
kinkthecontrolcable(Figure6).
Figure6
1.Controlcable
