Toro Power Clear 621 ZR - Installing the Discharge Chute; Filling the Engine with Oil

2
InstallingtheDischargeChute
Partsneededforthisprocedure:
3
Screws
1
Chuteassembly
1Dischargechutehandle
Procedure
Installthedischargechuteasshown(Figure7).
Figure7
1.Dischargechutehandle3.Dischargechute
2.Screw(3)
Note:Foreasierinstallation,useasmallratchetwrench
totightenthescrews.
Important:Donotovertightenthescrews;
otherwiseyoumaydamagethedischargechuteand
preventitfromturningfreely.
3
FillingtheEnginewithOil
NoPartsRequired
Procedure
Yourmachinedoesnotcomewithoilintheengine,but
itdoescomewithabottleofoil.
Important:Beforestartingtheengine,llthe
enginewithoil.
Note:Thebottleofoilmaycontainmorethanis
required.Donotoverllorunderlltheengine.
Maxll:20oz.(0.6l),type:automotivedetergentoil
withanAPIserviceclassicationofSJ,SL,orhigher.
Use
Figure8belowtoselectthebestoilviscosityforthe
outdoortemperaturerangeexpected:
Figure8
1.Movethemachinetoalevelsurface.
2.Cleanaroundtheoilllcap(Figure9).
Figure9
1.Oilllcap
3.Unscrewtheoilllcapandremoveit.
4.Withthemachineintheoperatingposition,
carefullypouroilintothecrankcaseuntilthepoint
ofoverow.
5.Wait3minutesfortheoiltosettleandaddenough
tobringittothepointofoverow .
6.Screwtheoilllcapintotheoilllholeandtighten
itsecurely.
6
