Toro Power Max 38624 - Checking the Traction Drive Operation; Checking the Tire Pressure; Checking the Skids and Scraper

Figure19
2.Installthedipsticksecurely.
Note:Donotspilloilaroundtheoillltube;oil
couldleakontotractionpartsandcausethetraction
toslip.
7.CheckingtheTirePressure
Procedure
Thetiresareoverinatedatthefactoryforshipping.
Reducethepressureequallyinbothtirestobetween17
and20psi(116and137kPa).
8.CheckingtheSkidsand
Scraper
Procedure
RefertoCheckingandAdjustingtheSkidsandScraper
inMaintenance.
9.CheckingtheTractionDrive
Operation
Procedure
Ifthetractiondriveisnotproperlyadjusted,
thesnowthrowermaymoveinthedirection
oppositeofwhatyouintended,causinginjury
and/orpropertydamage.
Carefullycheckthetractiondriveandadjustit
properly,ifnecessary.
1.Starttheengine;refertoStartingtheEngine.
2.MovethespeedselectortoPositionR1;referto
OperatingtheSpeedSelector.
3.Squeezethelefthand(traction)levertothehand-grip
(Figure20).
Figure20
Thesnowthrowershouldmoverearward.Ifthe
snowthrowerdoesnotmoveormovesforward,
completethefollowing:
A.Releasethetractionleverandstoptheengine.
B.Disconnectthetrunnionfromthespeedselector
lever(Figure11).
C.Turnthetrunniondownward(clockwise)onthe
speedcontrolrod(Figure11).
D.Connectthetrunniontothespeedselectorlever
(Figure11).
4.Releasethetractionlever.
5.MovethespeedselectortothePosition1;referto
OperatingtheSpeedSelector.
6.Squeezethelefthand(traction)levertothehand-grip
(Figure20).
Thesnowthrowershouldmoveforward.Ifthe
snowthrowerdoesnotmoveormovesrearward,
completethefollowing:
A.Releasethetractionleverandstoptheengine.
12
