6.MovethespeedselectorlevertoPosition6.
7.Lubricatetheotherendofthehexshaft.
8.Movethespeedselectorleverforwardandrearward
afewtimes.
9.Installthebackcoverandreturnthemachinetothe
operatingposition.
ReplacingtheSparkPlug
ServiceInterval:Every100hours—Replacethesparkplug.
WARNING
Replacingthesparkplugwhiletheengineishot
canresultinburns.
Waituntiltheengineiscooltoreplacethespark
plug.
UseaTorosparkplugorequivalent(Champion®RN9YCor
NGKBPR6ES).
1.Removetheboot(Figure55).
G016645
1
Figure55
1.Sparkplugboot
2.Cleanaroundthebaseofthesparkplug.
G016646
Figure56
3.Removeanddiscardtheoldsparkplug.
Note:Youwillneedaratchetwrenchextensionto
removethesparkplug.
4.Setthegapbetweentheelectrodesonanewsparkplug
at0.030inch(0.76mm)(Figure57).
Figure57
1.0.030inch(0.76mm)
5.Installthenewsparkplug,tightenitrmly,andattach
theignitionwiretothesparkplug.
Note:Ensuretheignitionwiresnapscompletelyinto
placeonthesparkplug.
AdjustingtheDischargeChute
Latch
Ifthedischargechutedoesnotlockintothedesiredposition
ordoesnotunlocksothatyoucanmoveittoanother
position,adjustthedischargechutelatch.
1.Removethefasteneronthegearcover(Figure58),lift
thefrontofthecoverup,andslideitbackandoutof
theway.
Figure58
2.Loosentheboltonthecableclamp(Figure59).
