g325789
Figure27
1.Hexheadadjustmentbolts
C.Ensurethatthedeectionofthetrackis
approximately9.5mm(3/8inch).
D.Tightenthenutsontherearrolleryoke.
E.Repeatfortheothertrack.
CheckingandAdjustingthe
TractionCable
ServiceInterval:Aftertherst2hours—Inspect
thetractioncableandadjustitif
necessary.
Yearly—Inspectthetractioncableandadjustor
replaceitifnecessary.
Ifthemachinedoesnotdriveintheforwardorreverse
speedsoritdriveswhenyoureleasethetractionlever,
adjustthetractioncable.
Withthetractionleveldisengaged,ensurethatthe
thereisnoslackinthetractioncable(Figure28).
g325790
Figure28
Ifthereisslackinthetractioncable,theleft(traction)
cableisnotproperlyadjusted.
Toadjustthetractioncable,dothefollowing:
1.Loosenthejamnut(Figure29).
2.Loosenortightentheturnbuckleuntilthecable
istaught.
3.Tightenthejamnut.
g325791
Figure29
1.Turnbuckle2.Jamnut
18

Toro Power TRX Commercial 1428 OHXE Specifications

General

Engine Type	4-Cycle
Engine Displacement	420cc
Clearing Width	28 inches
Drive System	Track Drive
Stages	Two-stage
Start Type	Electric Start
Transmission	Hydrostatic
Chute Rotation	200 degrees
Headlight	LED
Warranty	3-year limited
Fuel Type	Gasoline
Intake Height	21.5 inches
Impeller	14 inches
Speed Range	Variable
Skid Shoes	Adjustable
Auger Type	Serrated Auger
Chute Control	Quick Stick
