AdjustingtheCuttingHeightUsing
Matchcut
Anadditional6settingheightscanbeachievedusing
thematchcutheightsetting.Thisfeatureallowsthe
heightofcutselectorplatetoadjustbyonehalf
setting.
1.Loosentheselectorplateretainingboltwithan
Allenwrench(Figure12).
g281591
Figure12
1.Retainingbolt2.Matchcutadjuster
2.Turnthematchcutadjuster180°(Figure12and
Figure13).
Note:Anindicatorwillappearatthebottomof
theselectorplate,highlightingwhenmatchcut
isset.
g281590
Figure13
1.Matchcutindicator3.Matchcutadjuster
2.Selectorplate
3.Tightentheselectorplateretainingbolttoxthe
heightofcutselectorplateintoposition.
HeightSetting(with
Matchcut)
HeightofCut
1.516.9mm
2.524.8mm
3.532.6mm
4.540.4mm
5.5
48.3mm
6.556.1mm
11
