Hydraulic Schematic
C2
FD1
C1
P
P3P1 P2
TEST PORT FOR FRONT UNITS
(3)
STEERING CYLINDER
FORWARD SIDE OF CLOSED LOOP
SUNSTRAND M25
1.5 IN3 /REV
”A”
”A” SYSTEM RELIEF 3625 PSI
OUTPUT SHAFT TO DIFFERENTIAL
INPUT SHAFT 3200 RPM MAX
OIL COOLER
DIFFERENTIAL HOUSING
T
FOR REAR[R]UNITS
1250 PSI
3
AUX
STRAINER IN TANK 100 MESH
IN
OUT
TRW HGF 16
STEERING CONTROL VALVE
6.6 IN
TANK BREATHER 40 MICRON
INPUT SHAFT TO TRANSMISSION CCW ROTATION
100MESH
LH
RH
F
R
F
R
F
R
”C” ”B”
”D”
”E”
”B” CHARGE PRESSURE 150 PSI ”C” COOLER BY–PASS 70 PSI ”D” FILTER BY–PASS 70 PSI ”E” SYSTEM RELIEF 3625 PSI
F
R
F
R
M3 G2 M2
D2 P1 P2 G1 D1
M5 M4
S4A S3A S5A
TEST PORT
SYSTEM PRESSURE GAGE PORT ”A” CHARGE PRESSURE GAGE PORT ”B”
SYSTEM PRESSURE GAGE PORT ”E”
