Toro STX-26 User Manual

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
Grindercontrollever
1
1
Jamnut1
Installthegrindercontrollever.
2
Nopartsrequired
–
Checktheuidlevels.
3
Nopartsrequired
–
Chargethebattery.
1
InstallingtheGrinder
ControlLever
Partsneededforthisprocedure:
1
Grindercontrollever
1Jamnut
Procedure
1.Threadthejamnutontothegrindercontrollever
(Figure3).
g013175
Figure3
1.Grindercontrollever
3.4-pinconnector
2.Jamnut
2.Threadthegrindercontrolleverintothe
receptacleonthecontrolpanel(Figure3).
3.Withthetriggerorientedforward,tightenthejam
nutagainstthereceptacletosecuretheleverin
place(Figure3).
4.Connectthewireonthelevertothe4-pin
connectorunderthecontrolpanel(Figure3).
2
CheckingtheFluidLevels
NoPartsRequired
Procedure
Beforestartingtheengineforthersttime,check
theengine-oilandhydraulic-uidlevels.Refertothe
followingsectionsformoreinformation:
•CheckingtheEngine-OilLevel(page24)
•CheckingtheHydraulic-FluidLevel(page37)
3
ChargingtheBattery
NoPartsRequired
Procedure
Chargethebattery;refertoChargingtheBattery
(page29)formoreinformation.
