ReplacingtheFuses
Thereare4fusesintheelectricalsystem.Theyare
underthecontrolpanelontheleftside(Figure40).
Startcircuit
30A
Chargecircuit
25A
Coolerfancircuit
20A
Headlight(optional)
15A
g013185
Figure40
1.Fuseblock
DriveSystem
Maintenance
ServicingtheTracks
CleaningtheTracks
ServiceInterval:Beforeeachuseordaily
Checkthetracksforexcessivewearandcleanthem
periodically.Ifthetracksareworn,replacethem.
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowerthehydrauliclift.
2.Shutofftheengineandremovethekey.
3.Usingawaterhoseorpressurewasher,remove
dirtfromeachtracksystem.
Important:Ensurethatyouusehigh-pressure
watertowashonlythetrackarea.Donotuse
ahigh-pressurewashertocleantherestofthe
machine.High-pressurewashingcandamagethe
electricalsystemandhydraulicvalvesordeplete
grease.
Important:Ensurethatyoufullycleantheroad
wheelsandthedrivewheel(Figure41).Theroad
wheelsshouldrotatefreelywhenclean.
g013412
Figure41
1.Roadwheels3.Track
2.Drivewheel
