Toro Super Bagger 20192 - Changing the Engine Oil; Engine Oil Change Procedure; Lubricating the Upper Handle; Upper Handle Lubrication

ChangingtheEngineOil
ServiceInterval:Aftertherst5hours
Yearly
Changetheengineoilaftertherst5operating
hours;changeityearlythereafter.
Runtheengineafewminutesbeforechangingtheoil
towarmit.Warmoilowsbetterandcarriesmore
contaminants.
1.Performthepre-maintenanceprocedures;referto
PreparingforMaintenance.
2.Removethedipstick(
Figure38).
Figure38
3.Tipthemowerontoitsside,withtheairlterup,
todraintheusedoiloutthroughtheoillltube
(Figure39).
Figure39
4.Slowlypouroilintotheoillltube,periodically
checkingthelevelwiththedipstick,untilthedipstick
indicatesthattheengineisfullasillustratedin
Figure40.Wait3minutesafteraddingoiltocheck
theoillevelwiththedipstick.Donotoverll.(Max.
ll:0.58quart(0.55l),type:SAE30detergentoil
withanAPIserviceclassicationofSH,SJ,SL,or
higher.)
Note:Ifyouoverlltheengine,poursomeoilout
ofit.
Figure40
5.Installthedipsticksecurely.
6.Disposeoftheusedoilproperlyatalocalrecycling
center.
LubricatingtheUpperHandle
ServiceInterval:Yearly
Lubricatetheleftandrightsidesoftheupperhandle
withalow-viscositysiliconespraylubricantyearlyoras
needed.
1.Spraytheouterplasticendoftheinnerhandle
(
Figure41).
Figure41
Note:Usethestrawthatcomeswiththespraycan
todirectthespray.
2.Pushtheupperhandlefullydownandspraythe
innerplasticsurfaceoftheouterhandle(Figure42).
16
