Toro Super Bagger 20192 - Routine Checks and Adjustments; Checking the Engine Oil Level; Adjusting the Cutting Height; Adjusting the Upper Handle Height

CheckingtheEngineOilLevel
ServiceInterval:Beforeeachuseordaily
1.Removethedipstick,wipeitclean,andinsertitinto
theoilllerneck,butdonotscrewitin(Figure13).
Figure13
2.Removethedipstickandchecktheoillevel
(Figure13).
Ifthereisnooilonthedipstick,slowlypouroil
intotheoillltube,periodicallycheckingthelevel
withthedipstick,untilthedipstickindicatesthat
theengineisfullasillustratedin
Figure13.Wait3
minutesafteraddingoiltochecktheoillevelwith
thedipstick.Donotoverll.(Max.ll:0.58quart
(0.55l),type:SAE30detergentoilwithanAPI
serviceclassicationofSH,SJ,SL,orhigher.)
Note:Ifyouoverlltheengine,poursomeoilout
ofitasdirectedinChangingtheEngineOil.
3.Installthedipsticksecurely.
AdjustingtheCuttingHeight
WARNING
Adjustingthecuttingheightmaybringyouinto
contactwiththemovingblade,causingserious
injury.
•Stoptheengineandwaitforallmovingparts
tostop.
•Donotputyourngersunderthehousingwhen
adjustingthecuttingheight.
Adjustthecuttingheightasdesired.Setallfourwheels
tothesameheight.
Note:Toraisethemower,moveall4cuttingheight
leversforward;tolowerthemower,movethemrearward.
Figure14
AdjustingtheUpperHandle
Height
Youmayraiseorlowertheupperhandletoaposition
comfortableforyou.
Note:Youcannotraisetheupperhandlehigherthan
theangleofthelowerhandle.
1.Loosentheupperhandleknob(
Figure15).
Figure15
