InstalltheMulchPlugorGrass
Bag
NoPartsRequired
Procedure
Youmustcorrectlyinstallthemulchplug(formulching
orside-discharging)orgrassbag(forbagging)orthe
enginewillnotstart.
Themowerhasasafetyswitch,locatedatthebottom
ofachannelonthetop,rightrearofthemower,that
preventsthemowerfromoperatingwithoutamulch
plugorgrassbag.Thispreventsthemowerfrom
throwingdebrisattheoperatorthroughtherearchute.
Fortheswitchtodetectthepresenceofthemulchplug,
thetopofthemulchpluglevermustliefullyinthe
bottomofthechannel(
Figure6).
Figure6
1.Topofmulchplugleverinswitchchannel
1.Insertthemulchplugintothemower,ifitisn't
alreadyinstalled(
Figure7).
Figure7
2.Squeezethebuttonontheleverwithyourthumb
andfullyinsertthemulchplugintotheopening
(
Figure8).
Figure8
3.Releasethebuttonontheleverandensurethatthe
topoftheleverisliesfullyintheswitchchannel
(
Figure9).Ifthetopoftheleverisnotinthe
switchchannel,yourmowerwillnotstart!
Figure9
