Toro Super Recycler 20092C User Manual

Side-dischargingtheClippings
Usethesidedischargeforcuttingverytallgrass.
Ifthebagisonthemower,removeitandinserttherear
dischargeplug(refertoRemovingtheGrassBag)before
side-dischargingtheclippings.
Important:Ensurethatthereardischargeplugis
securelyinplace.Liftupthedischargedeector
andlookfor2tabsinfrontoftheplug(Figure28).
Ifyoudonotseethem,rmlypushthepluginuntil
itsnapsintoplace(Figure29).
Figure28
1.Tabs
Figure29
1.Dischargedeector
2.Reardischargeplug
Thebladeissharp;contactingthebladecan
resultinseriouspersonalinjury.
Stoptheengineandwaitforallmovingpartsto
stopbeforeleavingtheoperatingposition.
InstallingtheSideDischargeChute
1.Unlockthesidedischargedoor(Figure30).
Figure30
2.Liftopenthesidedischargedoor(Figure31).
Figure31
3.Installthesidedischargechuteandclosethedoor
ontothechute(Figure32).
Figure32
RemovingtheSideDischargeChute
Toremovethesidedischargechute,reversethesteps
above.
Important:Lockthesidedischargedoorafteryou
closeit(Figure33).
Figure33
13
