Toro Super Recycler 20095 - Setup; Assembling and Unfolding the Handle

Setup
Important:Removeanddiscardtheprotective
plasticsheetthatcoverstheengine.
1.AssemblingandUnfolding
theHandle
Procedure
Assemblingandunfoldingthehandle
improperlycandamagethecables,causingan
unsafeoperatingcondition.
•Donotdamagethecableswhenassembling
andunfoldingthehandle.
•Ensurethatthecablesareroutedtothe
outsideofthehandle.
•Ifacableisdamaged,contactanAuthorized
ServiceDealer.
1.Raisetherearofthemowerhousingtoitshighest
cuttingheightsettingbymovingthe2rearcutting
heightleversallthewayforward.RefertoAdjusting
theCuttingHeightintheOperationsection.
2.Attachthehandleendstothemowerhousingwith
2washersand2handlebolts(Figure3),butdonot
tightenthehandlebolts.
Figure3
1.Washer3.Handleend
2.Handlebolt
Important:Routethecablestothe outside of
thehandle(Figure3).
3.Rotatethehandlerearward(Figure4).
Figure4
4.Lockthehandleatyourdesiredheight.Referto
AdjustingtheHandleHeightintheOperation
section.
5.Torquethehandleboltsto120to160in-lb(14to
17N⋅m).
6.Adjustthecuttingheight.RefertoAdjustingthe
CuttingHeight.
6
