Toro Super Recycler 20095 - Setup Procedures; Filling the Engine with Oil; Installing the Fuse; Charging the Battery

2.InstallingtheStarterRope
Procedure
Pullthestarterropethroughtheropeguideonthe
handle(Figure5).
Figure5
1.Starterrope
2.Ropeguide
Note:Tomaketheropeeasiertoinstall,squeezethe
controlbaronthehandle.
3.FillingtheEnginewithOil
Procedure
Yourmowerdoesnotcomewithoilintheengine.
1.Removethedipstick(Figure6).
Figure6
2.Slowlypouroilintotheoillltubeuntiltheoillevel
reachestheFulllineonthedipstick(Figure6).Do
notoverll.(Max.ll:20oz.(0.59l),type:SAE
30WdetergentoilwithanAPIserviceclassication
ofSF,SG,SH,SJ,SL,orhigher.)
3.Installthedipsticksecurely.
Important:
Change the engine oil after the r st
5 operating hour s ;changeityearlythereafter.
RefertoChangingtheEngineOil.
4.InstallingtheFuse
Procedure
Electric-startmodelsonly
Yourmowercomeswitha40-ampfusethatprotectsthe
electricstarter.
Important:Youcannotstartthemowerwiththe
electricstarterorchargethebatteryunlessyou
installthefuse.
1.Unclipbothendsofthebatterycoverandremoveit
(Figure7).
Figure7
2.Installthefuseinthefuseholder(Figure8).
Figure8
Note:Yourmowercomeswithafuseintheyour
owner’spacketandanotherfuseinthebatterybox.
3.Installthebatterycover.
5.ChargingtheBattery
Procedure
Electric-startmodelsonly
RefertoChargingtheBatteryintheMaintenance
section.
7
