g189390
Figure30
2.Plugthechargerintoawalloutlet.
Note:Whenthebatterynolongerholdsa
charge,recycleordisposeofthelead-acid
batteryaccordingtolocalcodes.
Note:Yourbatterychargermayhavea2-colorLED
displaythatindicatesthefollowingstatesofcharging:
•Aredlightindicatesthatthechargerischarging
thebattery.
•Agreenlightindicatesthatthechargerisfully
chargedorthechargerisdisconnectedfromthe
battery.
•Aashinglightthatalternatesbetweenredand
greenindicatesthatthebatteryisnearlyfully
charged.Thisstatelastsonlyafewminutesuntil
thebatteryisfullycharged.
ReplacingtheFuse
Electric-StartModelOnly
Ifthebatterydoesnotchargeortheenginedoesnot
runwiththeelectricstarter,thefusemaybeblown.
Replaceitwitha40Aplug-intypefuse.
1.Removethecoverfromthebatterycompartment
(Figure31).
2.Pulloutthebatteryandlocatethefuse(Figure
31).
3.Replacethefuseinthefuseholder(Figure31).
g189463
Figure31
1.Cover
4.Batterycompartment
2.Fuseholder5.Fuse
3.Sparefuse
Note:Yourmachinecomeswithasparefusein
thebatterycompartment.
4.Installthecoveroverthebatterycompartment
(Figure31).
LubricatingtheWheel
Gears
ServiceInterval:Every25hours
1.Wipethegreasettingsjustinsidetherear
wheelswithacleanrag(Figure32).
g003234
Figure32
1.Greasetting
2.Installagreasegunontoeachttingandgently
apply2or3pumpsofNo.2lithiumgrease.
28

Toro Super Recycler Specifications

General

Cutting Width	22 inches
Mulching Capability	Yes
Bagging Capability	Yes
Side Discharge	Yes
Start Type	Recoil start
