16 Power LED
17 Daughter Board Fuse (8), 3.15A Fast-Blow
Daughter Board Components
66
1 Station Watering LED
2 Pump ON LED
3 Pump Pressure LED
4 Rain Sensor LED
5 Power LED
6 PC Connection LED
7 Tx LED
8 Rx LED
9 Mother Board Fuse, 3.15A Slow-Blow
10 Timing Mechanism Cable Socket
11 RS-232 Fiber/Wire Switch
12 Pump Output
13 Pump Pressure Input
14 Rain Switch Input
15 RS-232 Input
Mother Board Components
Mother Board
Daughter Board
1
2
3
4
5
6
7
8
15
14
13
12
11
10
16
9
17
