Toro TimeCutter 4200C

To Next Page

To Previous Page

MaintenanceService

Interval

MaintenanceProcedure

Every300hours

•Checkandadjustthevalveclearance.ContactanAuthorizedServiceDealer.

Beforestorage

•Chargethebatteryanddisconnectthebatterycables.

•Performallmaintenanceprocedureslistedabovebeforestorage.

•Paintanychippedsurfaces.

Important:Refertoyourengineowner'smanualforadditionalmaintenanceprocedures.

CAUTION

Ifyouleavethekeyintheswitch,someonecouldaccidentlystarttheengineandseriously

injureyouorotherbystanders.

Shutofftheengineandremovethekeyfromtheswitchbeforeyouperformanymaintenance.
