DisengagingtheBlade-Control

Switch(PTO)

g009174

Figure17

OperatingtheThrottle

YoucanmovethethrottlecontrolbetweentheFAST

andSLOWpositions(Figure18).

AlwaysusetheFASTpositionwhenengagingthePTO.

g187517

Figure18

OperatingtheChoke

Usethechoketostartacoldengine.

1.Pullupthechokeknobtoengagethechoke

beforeusingthekeyswitch(Figure19).

Note:Ensurethatyoufullyengagethechoke.

Youmayneedtoholdtheknobupwhenyou

usethekeyswitch.

2.Pushdownthechoketodisengagethechoke

aftertheenginehasstarted(Figure19).

g295540

Figure19

1.ONposition2.OFFposition
