Lubrication
GreasingtheBearings
Machineswitha107cm(42inch),
127cm(50inch),or137cm(54
inch)MowerDeckOnly
ServiceInterval:Every25hours—Greaseall
lubricationpoints(107cm(42inch),
127cm(50inch),or137cm(54
inch)MowerDeckOnly).
Important:Thisproceduredoesnotapplyto
MyRidemodels.
GreaseType:No.2lithiumgrease
1.Disengagetheblade-controlswitch(PTO),move
themotion-controlleverstotheNEUTRAL-LOCK
position,andengagetheparkingbrake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Cleanthegreasettings(Figure33andFigure
34)witharag.
Note:Makesuretoscrapeanypaintoffthe
frontofthetting(s).
g032432
Figure33
1.Frontcastertire
decal106-8717
Figure34
Locatedontheseat-panunderside
1.Readtheinstructions
beforeservicingor
performingmaintenance.
3.Greaseevery25operating
hours.
2.Checkthetirepressure
every25operatinghours.
4.Engine
4.Connectagreaseguntoeachtting(Figure33
andFigure34).
5.Pumpgreaseintothettingsuntilgreasebegins
tooozeoutofthebearings.
