AdjustingtheHeightofCut
Note:Thetransportpositionisthehighestheight-of-cut
positionorcuttingheight4.5inch[115mm](Figure19).
Height-of-cutiscontrolledbytheleverlocatedtotherightof
theoperatingposition(Figure19).
Figure19
AdjustingtheAnti-Scalp
Rollers
Wheneveryouchangetheheight-of-cut,adjusttheheight
oftheanti-scalprollers.
Note:Adjusttheanti-scalprollerssotherollersdonottouch
thegroundinnormal,atmowingareas.
1.Disengagethebladecontrolswitch(PTO),movethe
motioncontrolleverstotheneutrallockpositionand
settheparkingbrake.
2.Stoptheengine,removethekey,andwaitforallmoving
partstostopbeforeleavingtheoperatingposition.
3.Adjusttheanti-scalprollersasshowninFigure20to
matchtheclosestheight-of-cutposition.
G010233
1
2
3
4
Figure20
1.Anti-scalproller3.FlangeNut
2.Bolt4.Holespacing
PositioningtheSeat
Theseatcanmoveforwardandbackward.Positiontheseat
whereyouhavethebestcontrolofthemachineandaremost
comfortable.
Figure21
