Toro TimeCutter MX 5075T - Raising the Machine; Pre-Maintenance Procedures; Releasing the Mower-Deck Curtain

Pre-Maintenance
Procedures
ReleasingtheMower-Deck
Curtain
Loosenthe2bottomboltsofthecurtaintoaccessthe
topofthemowerdeck(Figure35).
g295619
Figure35
1.Bottombolt
2.Curtain
Note:Alwaystightentheboltstoconnectthecurtain
aftermaintenance.
RaisingtheMachine
Usejackstandstosupportthemachinewhenyou
raiseit.
WARNING
Supportingthemachineonthelowermufer
shield(Figure36)maydamagetheshieldand
causethemachinetofall,injuringyouor
bystanders.
Donotusethelowermufershieldtoliftor
supportthemachine.
g299647
Figure36
1.Lowermufershield
