Toro TimeCutter SS3225 User Manual

ReplacingtheGrass
Deector
ServiceInterval:Beforeeachuseordaily—Inspect
thegrassdeectorfordamage.
WARNING
Anuncovereddischargeopeningcouldallow
themachinetothrowobjectstowardyouor
bystanders,resultinginseriousinjury.Also,
contactwiththebladecouldoccur.
Neveroperatethemachinewithoutthe
grassdeector,thedischargecover,orthe
grass-collectionsysteminplace.
1.Removethenut(3/8inch)fromtherodunder
themower(Figure65andFigure66).
g014636
Figure65
81cm(32-Inch)Deck
1.Mowerdeck
5.Spring
2.Grassdeector6.Nut(3/8inch)
3.Grass-deectorbracket7.Shortstandoff
4.Rod
g005192
Figure66
107cm(42-Inch)Deck
1.Mowerdeck
5.Spring
2.Grassdeector6.Nut(3/8inch)
3.Grass-deectorbracket7.Shortstandoff
4.Rod
2.Slidetherodoutoftheshortstand-off,spring,
andgrassdeector(Figure65andFigure66).
3.Removethedamagedorworngrassdeector.
4.Replacethegrassdeector(Figure65and
Figure66).
5.Slidetherod(straightend),throughthe
rear-grass-deectorbracket.
6.Placethespringontherod,withtheendwires
down,andbetweenthegrassdeectorbrackets.
7.Slidetherodthroughsecondgrassdeector
bracket(Figure65andFigure66).
8.Inserttherodatthefrontofthegrassdeector
intotheshortstandoffonthedeck.
9.Securetherearendoftherodintothemower
withanut(3/8inch)asshowninFigure65
andFigure66.
Important:Thegrassdeectormustbe
springloadedinthedownposition.Liftthe
deectoruptotestthatitsnapstothefull
downposition.
49

Toro TimeCutter SS3225 Specifications

General

Engine Displacement	452cc
Engine Brand	Toro
Cutting Width	32 inches
Transmission	Hydrostatic
Blade Quantity	2
Deck Material	Steel
Cutting Height	1.5 - 4.5 inches
Fuel Capacity	3 gallons
