Premaintenance
Procedures
RaisingtheSeat
Ensuretheparkingbrakeisengagedandlifttheseatforward.
Thefollowingcomponentscanbeaccessedbyraisingtheseat:
•Serialplate
•Servicedecal
•Seat-adjustmentbolts
•Fuellter
•Batteryandbatterycables
ReleasingtheMower-Deck
Curtain
Loosenthe2bottomboltsofthecurtaintogainaccesstothe
topofthemowerdeck(Figure29).
Figure29
1.Bottombolt2.Mower-deckcurtain
RaisingtheFrontofthe
Machine
Ifthefrontofthemachineneedstoberaised,usethevery
frontedgeasshowinFigure30.
Important:Topreventdamagetothesteering
mechanism,ensuretheveryfrontedgeofthemachine
isusedforjackingpoints.
Figure30
33
