Toro TimeCutter Z4235 - Engine Oil Check and Service; Checking Engine Oil Level

Every100hours—Servicethepaper
element.(moreoftenindusty,dirty
conditions)
Every200hours/Yearly(whichever
comesrst)—Replacethepaper
element.(moreoftenindusty,dirty
conditions)
1.FoamElement
A.Washthefoamelementinliquidsoapand
warmwater.Whentheelementisclean,rinse
itthoroughly.
B.Drytheelementbysqueezingitinacleancloth
(donotwring).Allowtheelementtoairdry.
Important:Replacethefoamelementifit
istornorworn.
2.PaperElement
A.Lightlytaptheelementonaatsurfaceto
removedustanddirt.
B.Inspecttheelementfortears,anoilylm,and
damagetotheseal.
Important:Nevercleanthepaperelement
withpressurizedairorliquids,suchas
solvent,gas,orkerosene.Replacethepaper
elementifitisdamagedorcannotbecleaned
thoroughly.
ServicingtheEngineOil
OilType:Detergentoil(APIserviceSF,SG,SH,SJ,
orSL)
CrankcaseCapacity:1.9qt(1.8l),[whenoillteris
removed:2.2qt(2.1l)]
Viscosity:Seethetablebelow.
SAEV iscosityGrades
SAE40
SAE30
SAE10W– 30/ SAE10W– 30
-2002032406080100
-30-20-10010203040
°F
°C
STARTING TEMPERA TURERANGE ANTICIPATEDBEFORENEXT OIL CHANGE
SAE5W– 20
G010686
Figure27
Note:Usingmultigradeoils(5W-20,10W-30,and10W
-40)willincreaseoilconsumption.Checkoillevelmore
frequentlywhenusingthem.
CheckingtheEngineOilLevel
ServiceInterval:Beforeeachuseordaily
Note:Checktheoilwhentheengineiscold.
WARNING
Contactwithhotsurfacesmaycausepersonal
injury.
Keephands,feet,face,clothingandotherbody
partsawaythemuferandotherhotsurfaces.
Important:Donotoverllthecrankcasewithoil
becausedamagetotheenginemayresult.Donot
runenginewithoilbelowthelowmarkbecausethe
enginemaybedamaged.
1.Parkthemachineonalevelsurface,disengagethe
bladecontrolswitch,stoptheengine,engageparking
brake,andremovethekey.
2.Makesuretheengineisstopped,level,andiscoolso
theoilhashadtimetodrainintothesump.
3.Tokeepdirt,grassclippings,etc.,outoftheengine,
cleantheareaaroundtheoilllcap/dipstickbefore
removingit.
4.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position(
Figure28).
27
