Toro TimeCutter ZS 5000 Installation Instructions

2
AssemblingtheDeckBelt
Guard
Partsneededforthisprocedure:
1
Leftdeckguardplate
1Rightdeckguardplate
1Topdeckguardplate
4
HexBolt(M6-1X16)
4
Locknut(NIM6-1)
Procedure
Assembletheleft,rightandtopdeckguardplatesusing
4hexboltsand4locknutsasshowninFigure1.
Figure1
1.HexBolt(M6-1X16)(4)4.Locknut(NIM6-1)(4)
2.Leftdeckguardplate
5.Rightdeckguardplate
3.Topdeckguardplate
3
InstallingtheDeckBeltGuard
NoPartsRequired
Procedure
1.Loosen,butdonotremove,theangenutonthe
outsideofeachsuspensionbracketontherearofthe
deck;seeFigure2.
Figure2
1.Knob,existing3.Bolt,existing
2.Washer,existing4.Flangenuts
2.Removetheknob,washerandboltshowninFigure2
andsetthemaside.
3.Mounttheassembleddeckbeltguardontothedeck.
A.Attachthetabatthefrontoftheguardtothe
deckusingtheexistingbolt,washerandknob
thatyoujustsetaside;seeFigure3.
