Figure3
1.Washer,existing
4.Rearslots,pair(2)
2.Knob,existing5.Bolt,existing
3.Flangenut,existing(2)
6.Tab
B.Foreachsideoftheguard,insertthepreviously
loosenedangenutthroughthelargeopening
andslidetheboltintotheslotthattsbest
(Figure3).
C.Tightenbothangenutsandtheknobsecurely.
4.Verifythattheguardisclearofallmovingparts
acrosstheirfullrangeofoperation,thatitwillnot
causedamagetowires,hosesorothercomponents
andthatitwillnotinterferewiththesafeoperation
ofthecuttingdeck.
4
AttachingtheDeck
NoPartsRequired
Procedure
1.Slidethedeckbackunderthemachine,mountitto
thetractionunitandadjustitasdescribedinthe
Operator’sManualforthismodel.
2.Verifythatthebeltguardsareclearofallmoving
partsacrosstheirfullrangeofoperation,thatthey
willnotcausedamagetowires,hosesorother
componentsandthattheywillnotinterferewiththe
safeoperationofthemowingdeckandthetraction
unit.
