RemovingtheRightBafefor
Side-Discharging
1.Parkthemachineonalevelsurface,disengage
theblade-controlswitch,andengagetheparking
brake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Removetherightmowerblade;referto
RemovingtheBlades(page52).
4.Removethe2knobsandcurvedwashersthat
securetherightbafetothemower(Figure16).
g005655
Figure16
1.Knob
3.Bafestudcomingthrough
themower
2.Curvedwasher
5.Removetherightbafeandlowerthegrass
deectoroverthedischargeopeningasshown
inFigure16andFigure17.
g024261
Figure17
1.Rightbafe
3.Dischargeopening
2.Curvedwasherandknob
6.Installfastenersintotheholesinthetopofthe
mowertopreventyingdebris.
WARNING
Openholesinthemachineexposeyou
andotherstothrowndebristhatcan
causesevereinjury.
•Neveroperatethemachinewithout
hardwaremountedinallholesinthe
machinehousing.
•Installthehardwareinthemounting
holeswhenyouremovethemulching
bafe.
7.Installtherightmowerblade;refertoInstalling
theBlades(page53).
8.Liftupthegrassdeector.Install2bolts(5/16x
3/4inch)tothe2holesalongthedeckcutout.
9.Installthecutoffbafetothemowerdeck(Figure
18).
Note:Usethe2locknuts(5/16inch)tosecure
thebafetothemowerdeck.
Note:Thecutoffbafewasshippedwiththe
machineasaloosepart.
23
