G017514
Figure34
9.Wipeoffthedipstickendwithacleancloth.
10.Insertthedipstickintotheoil-lltube,andscrewit
inuntilitstops.
11.Removethedipstickandreadtheoillevelonthe
dipstick;refertoFigure35.
Figure35
1.Theoillevelistoolow;
addoiltothecrankcase.
3.Theoilleveliscorrect.
2.Theoillevelistoohigh;
removeoilfromthe
crankcase.
•Iftheoillevelistoolow,addasmallamountofoil
slowlytotheoil-lltube,andthenrepeatsteps9
through11untiltheoilleveliscorrectasshownin
Figure35.
•Iftheoillevelistoohigh,draintheexcessoiluntil
youobtainthecorrectoillevelonthedipstick.To
draintheexcessoil,refertoChangingtheEngine
Oil(page18).
Important:Iftheoillevelinthecrankcaseis
toolowortoohighandyouruntheengine,
youmaydamagetheengine.
12.Installthedipsticksecurelybyhand.
13.Recycletheusedoil.
ChargingtheBattery
ServiceInterval:Every25hours
Beforestorage
Electric-startmodelonly
WARNING
Batteryposts,terminals,andrelatedaccessories
containleadandleadcompounds,chemicals
knowntotheStateofCaliforniatocausecancer
andreproductiveharm. W ash hands after handling
batter y .
Chargethebatteryfor24hoursinitially,thenmonthly(every
25starts)orasneeded.Alwaysusethechargerinasheltered
area,andchargethebatteryatroomtemperature(about22°
C,or70°F)wheneverpossible.
Note:Themachineisequippedwithanalternatorcharging
system.
1.Connectthechargertothewiringharness,whichis
locatedbelowtheignitionkey(Figure36).
G017518
Figure36
2.Plugthechargerintoawalloutlet.
Note:Yourbatterychargermayhavea2-colorLEDdisplay
thatindicatesthefollowingstatesofcharging:
•Aredlightindicatesthatthechargerischargingthe
battery.
•Agreenlightindicatesthatthechargerisfullychargedor
isdisconnectedfromthebattery.
•Aashinglightthatalternatesbetweenredandgreen
indicatesthatthebatteryisnearlyfullycharged.Thisstate
lastsonlyafewminutesuntilthebatteryisfullycharged.
Note:Whenthebatterynolongerholdsacharge,recyclethe
lead-acidbatteryaccordingtolocalcodes.
19
