4. Technical data
Recommended operating pressure 72.5 to 116 psi
Permitted operating pressure 43.5 to 145 psi
WARNING!
The pressure at the sprinkler must not exceed 145 psi.
Connection thread: G1½” NPT
Liquids: Water
Liquid temperature: 104° F max.
Ambient temperature: 140° F max.
For further data see separate data sheet.
5. Assembly, set-up and installation
5.1 Hazard warnings
!
If any impurities get into the sprinkler, it is possible that the sprinkler could be destroyed
and that tters could be injured. Flush out the line thoroughly before connecting the water
supply.
!
Any unexpected emergence of a jet of water can lead to serious injury.
Make sure that the installation has been fully completed before turning on the water supply.
5.2 Installation instructions
• e thread connection on the pop-up sprinkler is 1½" NPT.
• For the thread seal, use hemp and sealing compound, e.g. Fermit Spezial or teon tape.
• e pop-up sprinkler should be tted in accordance with the 'Triton-L pop-up sprinkler installation
diagram' (see next page). In order to avoid any load pressure on the main line, you should denitely
use a exible connection.
• Providing a drainage pit directly connected to the drainage, as shown in the installation diagram, is
strongly recommended.
• For screwing in the connection joint the housing or housing edge of the pop-up sprinkler can be
rmly held or clamped.
