Parking-BrakeLever
•Toengagetheparkingbrake,pushthelever
forwardandtotheleftandthenpullitrearward
(Figure13).
Note:Thetractionunitmayrollslightlybeforethe
brakesengageinthedrivesprocket.
•Toreleasethebrake,pushtheleverforwardand
thenright,intothenotch(Figure13).
g005552
Figure13
FuelGauge
Thisgaugemeasurestheamountoffuelinthefuel
tank(s).
Engine-OilPressureLight
Iftheengine-oilpressuregetstoolow,thislight
illuminatesandanaudiblealarmsounds.Ifthis
happens,shutofftheengineimmediatelyandcheck
theoillevel.Ifitislow,addoilandlookforpossible
leaks.
g004350
Figure14
1.Engine-oilpressurelight4.Battery-chargeindicator
light
2.Engine-coolant
temperaturelight
5.Glow-pluglight
3.Glow-plugswitch
Battery-ChargeIndicatorLight
Ifthebatterychargebecomestoolow,thislight
illuminatesandanaudiblealarmsounds.Ifthis
happens,shutofftheengineandchargeorreplace
thebattery.Checkthetensionofthealternatorbelt;
refertoyourengineowner’smanual.
Engine-CoolantTemperatureLight
Iftheenginecoolantgetstoohot,thislightilluminates
andanaudiblealarmsounds.Ifthishappens,shutoff
theengineandallowthetractionunittocool.Check
thecoolantlevelwhentheenginehasfullycooled.
Glow-PlugLight
Thislightilluminateswhiletheglowplugsarecharged
andwarmingtheengine.
Glow-PlugSwitch
Pressandholdthisswitchfor10secondstoactivate
theglowplugsbeforestartingtheengine.
