ClosingtheHood
1.Liftuponthetabsecuringtheproprod(Figure
25)
g007360
Figure25
1.Prop-rodtab
2.Lowerthehoodandsecureitbypushingdown
onthefrontofthehooduntilitlocksinplace.
3.Tightenthehood-lockingscrewtosecurethe
latch(Figure24).
OpeningtheRear-AccessCover
1.Unscrewthe2handknobssecuringthe
rear-accesscovertothemachine(Figure26).
g244210
Figure26
1.Handknobs
2.Tilttherear-accesscoverdownandremoveto
accesstheinternalcomponents(Figure26).
ClosingtheRear-AccessCover
1.Movetherear-accesscoverinplaceoverthe
backofthemachine;ensurethatthetabsline
upintheslots.
2.Pushtheaccesscoverforward,liningupthe
hand-knobscrewswiththethreadedholesin
themachine.
3.Screwthehandknobstighttosecurethe
rear-accesscoverinplace.
RemovingtheSideScreens
1.Openthehood.
2.Slidethesidescreens(Figure27)upandoutof
theslotsinthefrontscreenandframe.
g004352
Figure27
1.Sidescreen
InstallingtheSideScreens
Slidethesidescreensintoplaceintheslotsinthe
frontscreenandframe.
