Toro Workman GTX Series Installation Instructions

RemovingthePlasticCargo
Bed
1.Usinganoverheadhoist,raisetheplasticcargobed.
2.Removethe3ange-headscrews(5/16x3/4inch)
andproprodUbracketfromtheproprod(Figure2).
Note:Retainthehardwareifyouwanttoinstallthe
plasticcargobedinthefuture.
Figure2
1.ProprodUbracket3.Proprod
2.Flange-headscrew(5/16
x3/4inch)
3.Slidetheproprodforwardoutofthedetentslotand
removetheproprod(Figure3).
Figure3
1.Detentslot2.Proprod
4.Usinganoverheadhoist,lowerthecargobed.
5.Removethe2pivotbolts(1/2x4-1/2inches)and2
locknuts(1/2inch)fromthepivotbracketlocatedat
therearofthemachine(Figure4).
Note:Retainthehardwareifyouwanttoinstallthe
plasticcargobedinthefuture.
Figure4
1.Pivotbolt(1/2x4-1/2
inches)
3.Locknut(1/2inch)
2.Pivotbracket
6.Releasethecargo-bedleverandraisethecargobed
usinganoverheadhoist.
