Toro Workman GTX Series Installation Instructions

InstallingStakeSides
Optional
Toinstalltheoptionalstakesides,youneedthefollowingmeasurementsandquantitiesofwood:
WoodDimensions
TotalLengthofEachBoardQuantityNeeded
38x89mm(2x4inch)36cm(14inches)
8
29x140mm(5/4x6inch)117cm(46inches)
8
Youalsoneedthefollowinghardware:
HardwareUse
QuantityNeeded
Button-headbolt(5/16-18x3inches)Mountingthe29x140mm(5/4x6inch)
boardstothe38x89mm(2x4inch)
boards
32
Button-headbolt(5/16-18x2-1/2inches)Mountingthe38x89mm(2x4inch)
boardstothebed
16
Flangednylocnut(5/16-18inch)Securingthehardware
48
Yourstructureshouldappearasfollows:
Figure11
1.29x140mm(5/4x6inch)board3.38x89mm(2x4inch)board
2.Frontofthestructure—ensurethattheboardsareoriented
asshown.
5
