Workman MD/MDX Page 7 -- 45 Chassis
Removal (Fig. 33)
NOTE: If cargo box has been replaced with newer box
design, refer to Cargo Box (Serial Numbers Above
311000000) in this section.
1. Park machine on a level surface, stop engine, set
parking brake and remove key from the ignition switch.
2. Disassemble cargo box as necessary using Figure
33 as a guide.
Installation (Fig. 33)
1. Assemble cargo box using Figure 33 as a guide.
A. When installing tailgate and tailgate hardware,
use torque specifications identified in Figure 33.
B. Adjust latch pin (item 20) so that cargo box is tight
to frame when latched.
Chassis
Rev. A
