Toro Z449 Z Master User Manual

Ser vicing the Hy draulic
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Setting the Hy draulic Pump
Neutral P osition . . . . . . . . . . . . . . . . 44
Mo w er Dec k Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . 46
Lev eling the Mo w er at T hree
P ositions . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Ser vicing the Cutting Blades . . . . . . . . . . . . . . . 48
R e placing the Grass Deflector . . . . . . . . . . . . 50
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Cleaning Under the Mo w er . . . . . . . . . . . . . . . . 51
W aste Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Storag e . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
T roubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Sc hematics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Introduction
R ead this infor mation carefully to lear n ho w to
operate and maintain y our product properly and
to a v oid injur y and product damag e . Y ou are
responsible for operating the product properly
and safely .
Y ou ma y contact T oro directly at www .T oro .com
for product and accessor y infor mation, help
finding a dealer , or to register y our product.
W henev er y ou need ser vice , g en uine T oro par ts ,
or additional infor mation, contact an A uthorized
Ser vice Dealer or T oro Customer Ser vice and ha v e
the model and serial n umbers of y our product
ready . Figure 1 identifies the location of the model
and serial n umbers on the product. W rite the
n umbers in the space pro vided.
Figure 1
1. Model and serial number location
Model No.
Serial No.
T his man ual identifies potential hazards and has
safety messag es identified b y the safety aler t
symbol ( Figure 2 ), whic h signals a hazard that ma y
cause serious injur y or death if y ou do not follo w
the recommended precautions .
Figure 2
1. Safety alert symbol
