Torque F9 - Parts List

50 180
3
190150 170160
6
130 14012090 110100403010 706020 80
1 2 4 5 7
200
*
**
ITEM PART NUMBER DESCRIPTION QTY
1 5496201 BRKT, LOWER BASE CONNECTOR 1
2 54844PA PTD ASSY, RIGHT SIDE 1
3 54858PA PTD ASSY, LEFT SIDE 1
4 5496301 PLATE, LOWER BASE PULLEY 2
5 2001101 WASHER, FLAT 3/8 SAE ST ZN 98
6 2008411 BOLT, 3/8-16 X 3" (76mm) ST HT SOCKET HEAD 8
7 2001201 NUT, 3/8-16 LK ST ZN 46
8 5094401 PULLEY, 3-1/2 OD X 25 4
9 5485601 SPACER, 16 OD X 10.1 ID X 12 4
10 5496401 BRKT, UPPER SIDE CONNECTOR 1
11 2008410 BOLT, 3/8-16 X 2-3/4" (70mm) ST HT SOCKET HEAD 14
12 54861PA PTD ASSY, ACCESSORY HOLDER 1
13 2001013 BOLT, 3/8-16 X 3-3/4" BUTTON HEAD 2
14 54866PA PTD ASSY, CHIN-UP 1
15 5489201 GUIDE ROD, 19 OD X 1880 4
16 57094PA PTD ASSY, 10 LB WEIGHT PLATE 28
17 57388PA PTD ASSY, 15 LB WEIGHT PLATE 20
18 57097PA PTD ASSY, HEAD PLATE 2
19 54896PA PTD ASSY, GUIDE ROD SUPPORT 2
20 5513601 CUSHION, WEIGHT STACK 4
21 5095301 SHAFT COLLAR, GUIDE ROD 4
22 2008409 BOLT, 3/8-16 X 2-1/2" (64mm) ST HT SOCKET HEAD 6
23 5487101 WLDMT, CARRIAGE UPRIGHT 2
24 5506601 ASSY, RIGHT CARRIAGE 1
25 54880PA PTD ASSY, RIGHT DOOR 1
26 2009403 BOLT, 3/8-16 X 1" (25mm) ST HT SOCKET HEAD W/NP 2
27 5511401 PIN, DOOR PIVOT 4
28 5506701 ASSY, LEFT CARRIAGE 1
29 54889PA PTD ASSY, LEFT DOOR 1
ITEM PART NUMBER DESCRIPTION QTY
30 5466201 WHEEL, 3" OD X 1/2" ID X 1-1/2" 2
31 5466601 SPACER, WHEEL HUB 2
32 2008406 BOLT, 3/8-16 X 1-3/4" (45mm) ST HT SOCKET HEAD 4
33 5172501 PULLEY, 3-1/2" IDLER 2
34 2009406 BOLT, 3/8-16 X 1-3/4" (45mm) ST HT SOCKET HEAD W/NP 2
35 5500701 LABEL, WEIGHT STACK 1-20 2
36 5666401 ASSY, WEIGHT STACK PIN 2
37 55181PA PTD ASSY, WEIGHT SELECTOR STORAGE PLATE 2
38 2009402 BOLT, 3/8-16 X 3/4" (19mm) ST HT SOCKET HEAD W/NP 4
39 54970PA PTD ASSY, HEAD PLATE PULLEY 2
40 2002601 NUT, 1/2 JAM ST ZN 4
41 5709301 CABLE ASSY, F9-103 2
42 5508801 HOUSING, CABLE COUPLER 2
43 5508901 GROMMET, RUBBER CABLE 2
44 5509001 CORE, CABLE COUPLER 2
45 2003201 CAP SCREW, M5 X 0.8 X 6MM SOCKET HEAD 4
46 5493201 PANEL, DOOR SIDE 2
47 5493001 SPACER, SHROUD STAND OFF 8
48 2008415 BOLT, 3/8-16 X 4" (102mm) ST HT SOCKET HEAD 8
49 5493301 SHROUD, DOOR FRONT 1
50 5493101 SPACER, SHROUD STAND OFF 4
51 2008417 BOLT, 3/8-16 X 4-1/2" (114mm) ST HT SOCKET HEAD 4
52 5497501 STRAP, UNIVERSAL 1
53 5324601-A ASSY, LEG BOOT D-RING 1
54 5324701-A ASSY, SHORT STRAP HANDLE 2
55 5497601 ASSY, SQUAT HARNESS W D-RING 1
56 55192PA PTD ASSY, STRAIGHT BAR 1
57 5091801 SNAP HOOK, 8MM DIA X 80MM 2
58 5493701 WORKOUT BOOK, F9-101 1
5
NOTE:
The F9 has two weight stack options. 150 LBS. and 200 LBS.
* The 150 LB. stack has fourteen 10 LB. plates and a head plate.
** The 200 LB. stack has ten 15 LB. plates, 4 ten LB. plates and a
head plate.
