– 22 –
SPECIFIC INFORMATIONS
Location
No.
Part No. Description
Location
No.
Part No. Description
CAPACITORSCAPACITORS
CAPACITORSCAPACITORS
CAPACITORS
C103 24232103 CD, 0.01?F, +80%, -20%
C104 24232103 CD, 0.01?F, +80%, -20%
C107 24232103 CD, 0.01?F, +80%, -20%
C108 24232103 CD, 0.01?F, +80%, -20%
C109 24232103 CD, 0.01?F, +80%, -20%
C110 24232103 CD, 0.01?F, +80%, -20%
C112 24436150 CD, 15pF (28Z13G)
C113 24232103 CD, 0.01?F, +80%, -20%
(28Z13G)
C114 24794470 EL, 47?F, ±20%, 16V (28Z13G)
C114 24797229 EL, 2.2?F, ±20%, 50V
(28Z13B)
C115 24232103 CD, 0.01?F, +80%, -20%
C116 24503041 PF, 0.1?F, 63V
C117 24232103 CD, 0.01?F, +80%, -20%
C118 24794101 EL, 100?F, ±20%, 16V
C121 24232103 CD, 0.01?F, +80%, -20%
C123 24794221 EL, 220?F, ±20%, 16V
C124 24232103 CD, 0.01?F, +80%, -20%
C130 24436470 CD, 47pF (28Z13G)
C160 24794101 EL, 100?F, ±20%, 16V
C161 24797478 EL, 0.47?F, ±20%, 50V
C162 24212332 CD, 3300pF, ±10%
C165 24794100 EL, 10?F, ±20%, 16V
C166 24797010 EL, 1?F, ±20%, 50V
C168 24794100 EL, 10?F, ±20%, 16V
C169 24590103 PF, 0.01?F
C180 24797229 EL, 2.2?F, ±20%, 50V
C181 24212102 CD, 1000pF, ±10%
C183 24794101 EL, 100?F, ±20%, 16V
C188 24794100 EL, 10?F, ±20%, 16V
C189 24232103 CD, 0.01?F, +80%, -20%
C190 24232103 CD, 0.01?F, +80%, -20%
C199 24797100 EL, 10?F, ±20%, 50V
C216 24797478 EL, 0.47?F, ±20%, 50V
C221 24436100 CD, 10pF, ±0.25pF
C222 24436100 CD, 10pF, ±0.25pF
C223 24436100 CD, 10pF, ±0.25pF
C224 24794100 EL, 10?F, ±20%, 16V
C225 24503041 PF, 0.1?F, 63V
C226 24206108 EL, 0.1?F, ±20%, 50V
C233 24797010 EL, 1?F, ±20%, 50V
C302 24214471 CD, 470pF, ±10%, 500V
C303 24214471 CD, 470pF, ±10%, 500V
C305 24667222 EL, 2200?F, ±20%, 25V
C308 24797221 EL, 220?F, ±20%, 50V
C309 24591102 PF, 1000pF
C310 24795222 EL, 2200?F, ±20%, 25V
C313 24082057 PF, 0.22?F, 100V
C316 24795471 EL, 470?F, ±20%, 25V
C317 24214561 CD, 560pF, ±10%, 500V
C318 24794471 EL, 470?F, ±20%, 16V
C320 24795471 EL, 470?F, ±20%, 25V
C320 24796479 EL, 4.7?F, ±20%, 35V
C322 24617912 EL, 2.2?F, ±10%, 50V
C325 24590223 PF, 0.022?F
C326 24797010 EL, 1?F, ±20%, 50V
C327 24794471 EL, 470?F, ±20%, 16V
C332 24212102 CD, 1000pF, ±10%
C345 24591561 PF, 560pF
C366 24082049 PF, 0.047?F, 100V
C370 24794100 EL, 10?F, ±20%, 16V
C371 24797100 EL, 10?F, ±20%, 50V
C374 24797470 EL, 47?F, ±20%, 50V
C375 24797470 EL, 47?F, ±20%, 50V
C403 24590822 PF, 8200pF
C404 24797478 EL, 0.47?F, ±20%, 50V
C410 24214471 CD, 470pF, ±10%, 500V
C413 24214821 CD, 820pF, ±10%, 500V
C416 24678010 EL, 1?F, ±20%, 200V
C417 24214391 CD, 390pF, ±10%, 500V
C420 24794101 EL, 100?F, ±20%, 16V
C423 24829393 PF, 0.039?F, 400V
C431 24232103 CD, 0.01?F, +80%, -20%
C431 24232103 CD, 0.01?F, +80%, -20%
C432 24590103 PF, 0.01?F
C433 24794100 EL, 10?F, ±20%, 16V
C434 24794222 EL, 2200?F, ±20%, 16V
C435 24212102 CD, 1000pF, ±10%
C440 24082961 PF, 8200pF, ±3%, 1500V
C442 24082912 PF, 0.18?F, 315V
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY
PRECAUTION” AND “PRODUCT SAFETY NOTICE” ON PAGE 3 OF THIS MANUAL.
CAUTION: The international hazard symbols “ ” in the schematic diagram and the parts list designate com-
ponents which have special characteristics important for safety and should be replaced only with types identical to
those in the original circuit or specified in the parts list. The mounting position of replacements is to be identical with
originals. Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE. Do not
degrade the safety of the receiver through improper servicing.
NOTICE:
• The part number must be used when ordering parts, in order to assist in processing, be sure to include the Model
number and Description.
• The PC board assembly with
*
mark is no longer available after the end of the production.
Models : 28Z13B, 28Z13G
Capacitors ............. CD : Ceramic Disk PF : Plastic Film EL : Electrolytic
Resistors ............... CF : Carbon Film CC : Carbon Composition MF : Metal Film
OMF : Oxide Metal Film VR : Variable Resistor FR : Fusible Resistor
(All CD and PF capacitors are ±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)
CHASSIS AND CABINET REPLACEMENT PARTS LIST
