21-EN
ENGLISH
<Choose an air conditioner from area>
A Select [MAIN].
B Select [All Areas].
Choose an area.
C Select [UNIT].
D Choose an air conditioner which you want to
turn on or off.
E Push [ON] to turn on, and [OFF] to turn off.
Fig. 8-4 Choose from Area
<Choose an air conditioner from area by
tenant>
A Select [MAIN].
B Select [All Tenants].
Choose a tenant to which areas belong.
C Select [AREA].
Choose an area.
D Select [UNIT].
E Choose an air conditioner which you want to
turn on or off.
F Push [ON] to turn on, and [OFF] to turn off.
Fig. 8-5 Choose from Area by Tenant
<Choose an air conditioner from block/tenant/
area>
A Select [MAIN].
B Select [Whole Bldg].
Choose a block to which tenants belong.
C Select [TENANT].
Choose a tenant.
D Select [AREA].
Choose an area.
E Select [UNIT].
F Choose an air conditioner which you want to
turn on or off.
G Push [ON] to turn on, and [OFF] to turn off.
Fig. 8-6 Choose from Block/Tenant/Area
E A
B
C
D
F A
D
E
B
C
G A
E
F
B
C D
