Memory media slot This slot lets you insert an SD™/SDHC™/
SDXC™ memory card, miniSD™/microSD™
Card and MultiMediaCard™. Refer to the
Memory media section for more information.
Keep foreign metal objects, such as screws, staples, and paper clips, out of
the Memory media slot. Foreign metal objects can create a short circuit,
which can cause damage and fire, possibly resulting in serious injury.
Headphone/
Microphone combo
jack
A 3.5 mm mini headphone/microphone combo
jack enables connection of a monaural
microphone or stereo headphones.
Universal Serial Bus
(USB 3.0) port
One Universal Serial Bus port, which complies to
the USB 3.0 standard, is provided on the right
side of the computer.
The port with the icon ( ) has Sleep and Charge
function, and this function is only provided with
some models.
USB 3.0 port(s) might work as USB 2.0 port(s) when operating in USB
Legacy Emulation mode.
Before removing a USB device from the USB port of your computer,
click the Safely Remove Hardware and Eject Media icon on the
Windows Taskbar, and then select the USB device that you want to
remove.
Universal Serial Bus
(USB 2.0 or 3.0) port
One additional Universal Serial Bus port, which
complies to the USB 2.0 or 3.0 standard, is
provided on the right side of the computer.
HDMI out port HDMI out port can connect with Type A
connector HDMI cable.
Cooling vents The cooling vents help the processor to avoid
overheating.
Security lock slot A security cable can be attached to this slot and
then connected to a desk or other large object in
order to deter theft of the computer.
Back
The following figure shows the back of the computer.
User's Manual
3-4
